Hunan Huaxing Material Group Co., Ltd.

1)The leading product technology, complete function, excellent performance, reliable quality, easy to operate.

2)Optimization of body structure, special mold production, beautiful appearance, concrete mixing,discharge uniformity, low rate of residual.

3) Imported hydraulic pump, hydraulic motor and speed reducer.

4) Uses the high strength steel plate, long service life.

5) Optimization of the whole structure, low center of gravity, high running efficiency.

6) Product range is wide, the tank capacity of 6 to 18 cubic meters.

7) Choose a variety of auxiliary device.

8) Match all concrete mixer truck chassis.

9) based on strong technical support and top level technology make the trucks with high quality and more reliable
10) competitive price, cost-effective
11) quick and efficient spare parts supply bring you more convenient
12) fast delivery time, we can arrange production according to your needs exactly and quickly

13) professional import and export dealing procedure, make customs clearance more high efficiency

Specification

Model		ZZ5257GJBN3247C (8290)
Whole Vehicle Performance & Parameters	Chassis	HOWO
	Curb Weight (Kg)	13500
	Total Vehicle Weight (Kg)	25000
	Outline Dimension(LBH) (mm)	871524963800
	Wheelbase (mm)	3225+1350
	Front Overhang (mm)	1500
	Rear Overhang (mm)	2615
	Min. Clearance Above Ground (mm)	314
	Max. Traveling Speed (km/h)	90
	Min. Turning Diameter (m)	17.3
	Oil Consumption per 100 km (under limited conditions)	≤25
Vehicle Configuration	Clutch	Dry Single Disc Clutch (φ430)
	Gear Box	SINOTRUCK HW18709
	Driving Type	6*4
	Steering Mechanism	ZF8098
	Service Brake	Dual-circuit Air Brake
	Parking Braking	Spring-powered Air-cut-off Brake
	Auxiliary Brake	Engine Exhaust Brake
	Tyre	12.00(R)-20
Engine Parameters	Model	WD615.95(E);WD615.96(E)
	Type	In-line 6-cylinder, Water-cooled, Supercharged, Inter-cooled, Electric (Direct) Injection Diesel Engine
	Emission Standard	Euro III
	Discharge Capacity (L)	9.726L
	Power (HP)	290 HP(2200r/min)
	Max Torque	1350 N.m(1100-1600r/min)
Mixing Drum Parameters	Geometric Volume of Mixing Drum (m³)	12.8
	Max. Mixing Cubage (m³)	8-8.8
	Feeding Speed	≥3
	Discharging Speed	≥1.5
	Leftover Rate	≤0.5%
	Max Rotating Speed (r/min)	14-16
	Mixing Drum Obliquity (°)	15
	Max Mixing Drum Diameter (mm)	φ2162
Driving System	Speed Reducer	Italian BONFILI-577L
	Hydraulic Pump	US EATON5423-518
	Hydraulic Motor	US EATON4633-045
	Radiator	German AKG with Vacuum Meter
Water Supply System	Water Tank Capacity (L)	260
Water Supply System	Water Supply Mode	Water Pump
